Stable · Efficient · Green manufacturing—
Boyu SPC Flooring Extrusion Line helps you produce superior flooring!
The SPC Flooring Machine – Conical Twin-Screw Extruder is designed for superior performance and precision. It processes a blend of PVC powder, calcium carbonate, stabilizer, lubricant, and other essential materials to ensure high-quality SPC flooring production.
Our high-performance conical twin-screw extruder, certified by CE, guarantees efficiency, precision, and reliability, making it the ideal choice for your manufacturing needs.
With advanced technology and robust construction, the SPC flooring machine delivers exceptional precision and outstanding performance, setting a new benchmark in flooring production.
Extruder Model | Main Motor Power | Daily Capacity |
SJZ55 | 22kw | 60-80KG/H |
SJZ65 | 37kw | 150-160KG/H |
SJZ80 | 55kw | 220-250KG/H |
Extruder Model | Main Motor Power | Daily Capacity |
SJZ65 | 37kw | 150-160KG/H |
SJZ80 | 55kw | 220-250KG/H |
Extruder Model | Main Motor Power | Daily Capacity |
SJZ55 | 22kw | 60-80KG/H |
SJZ65 | 37kw | 150-160KG/H |
SJZ80 | 55kw | 220-250KG/H |
Mode | Yf800 | Yf1000 | Yf1250 |
Max Width of product | 800mm | 1000mm | 1250mm |
Extruder model | SJZ80/156 | SJZ92/188 | SJZ92/188 |
Extrude power | 55kw | 132kw | 132kw |
Max of extrusion capacity | 280kg/h | 600kg/h | 600kg/h |
Cooling water | 12m³/h | 15m³/h | 18m³/h |
Compressed air | 0.8m³/min | 1m³/min | 1.2m³/min |
Mode | JG-MSB80/156 | JG-MSB92/188 |
Screw dia. | Φ80/Φ156mm | Φ92/Φ188mm |
Screw quantity | 2 pieces | 2 pieces |
Screw speed | 1-38r/min | 1-32.9r/min |
Main extruder power | 55kw | 110kw |
Heating power | 36kw | 45kw |
Output | 150-350kg/h | 300-500kg/h |
